XCMG XC9150-EV
Weight: 59,000 kg
The XC9150-EV combines powerful performance with modern, zero-emission operation. The machine is designed for contractors and companies looking to reduce their operating costs and environmental impact without compromising on productivity, reliability, or comfort.
With advanced battery technology and an energy-efficient powertrain, XCMG’s electric wheel loaders deliver high torque right from the start. The result is quick response, strong breakout force, and a machine capable of handling demanding tasks in applications such as material handling, recycling, industry, construction sites, and agriculture.
-
Operating weight: 59,000 kg
Battery: 1,001 kWh CATL LFP (850 kWh usable)
Rated power: 910 kW (4 × 145 kW propulsion motors and 330 kW hydraulic motor)
Driving time: 5–7 hours
Power consumption (normal/aggressive driving): 105 kW/hour
Bucket capacity: 7,700 liters (7,000–10,300 liters, depending on the bucket)
Rated load: 15,000 kg
Tipping load: 42,000 kg straight, 36,000 kg at full swing
Breaking force: 360 kN
Maximum speed: 32 km/h
DC charging: up to 960 kW CCS2, approximately 50–60 minutes
Hydraulic flow: 642 l/min (two pumps)
Total cycling time: less than 16 seconds
-
1,001 kWh CATL battery
Engine power 910 kW
Premium comfort seat, electric, ventilated
Automatic door opener with remote control
Automatic Air Conditioning
DAB Bluetooth Radio
10-inch LED screen
SY-KLONE Pressurized Cabin Filter with Display
360° camera with auto-detection and emergency stop
App control for preheating, as well as battery and charging status
Weighing system
Height restriction
Electrically heated rear window
Heated and electrically adjustable rearview mirrors
BSS Loader Arm Suspension
BFS Float Mode
CDC Lever Control Danfoss
3-axis joystick
3rd hydraulic function
Centralized lubrication
L5 tire 35/65R33
14 LED lights and a strobe light bar on the cab roof
100 kW onboard charger
Main switch
Panolin S4 HLP Synthetic Hydraulic Oil
